WiFi







Monitoring and Analytics

WiFi monitoring and analytics serve a multitude of purposes, essential for both managing a network's health and optimizing its performance. WiFi monitoring and analytics tools are vital for ensuring a secure, efficient, and user-friendly network environment. They enable network administrators, businesses, and service providers to make informed decisions, enhancing both operational efficiency and user satisfaction.

What is for ?

Here's a breakdown of what WiFi monitoring and analytics are used for:

  • Network Performance Analysis
    • Traffic Management: Understand how data flows through the network, identifying high traffic periods and potential bottlenecks.
    • Signal Strength Mapping: Analyze coverage areas to pinpoint zones with weak signals, ensuring uniform coverage across the desired space.
  • User Behavior Insights
    • Device Tracking: Monitor the number and types of devices connecting to the network, helping to tailor the network for optimal device performance.
    • Application Usage: Identify which applications are being used and how much bandwidth they consume, allowing for better bandwidth allocation and prioritization.
  • Security and Compliance
    • Intrusion Detection: Spot unauthorized access or suspicious activities that could indicate a security breach.
    • Policy Enforcement: Ensure users and devices comply with network usage policies, identifying and mitigating potential violations.
  • Optimizing User Experience
    • Load Balancing: Distribute network traffic evenly across channels and access points to prevent any single device from being overwhelmed, enhancing the overall user experience.
    • Connection Quality: Measure and improve metrics such as latency, packet loss, and jitter to enhance VoIP quality, video streaming, and general internet use.
  • Network Planning and Expansion
    • Capacity Planning: Use data on current network usage and growth trends to plan for future expansions or upgrades.
    • Infrastructure Improvements: Identify the need for additional access points or network adjustments based on actual usage patterns and performance data.
  • Problem Diagnosis and Resolution
    • Troubleshooting: Quickly identify and resolve issues with connectivity, device configuration, or network settings to reduce downtime.
    • Predictive Analysis : Use historical data to predict future problems or to identify when network components might fail or become inadequate.
  • Enhancing Marketing and Business Strategies
    • User Engagement: For businesses, WiFi analytics can provide insights into customer behavior, such as dwell times and movement patterns within a venue, informing marketing strategies and operational improvements.
    • Customized Experiences: Enable personalized content delivery or targeted advertising based on user behavior and location within a WiFi-enabled space

High Level Use Cases

WiFi monitoring and analytics can be applied across various scenarios, providing critical insights and operational improvements in different environments. These use cases highlight the versatility of WiFi monitoring and analytics across different sectors, demonstrating how they can be leveraged to improve operations, enhance user experiences, and support business goals.

Here are some practical use cases:

  • Retail Stores
    • Customer Movement Tracking: Analyze the flow of customers through the store to identify high-traffic areas, optimizing store layout and product placement.
    • Engagement and Loyalty: Offer personalized promotions or information to customers based on their location within the store, enhancing customer engagement and loyalty.
  • Corporate Offices
    • Network Optimization: Monitor network performance to ensure stable and fast connectivity for critical business operations, identifying and resolving issues before they impact productivity.
    • Resource Allocation: Use analytics to understand the demand on network resources during peak times, and allocate bandwidth to prioritize critical business applications.
  • Healthcare Facilities
    • Patient and Staff Tracking: Employ WiFi-based location services to track the movement of patients and staff, improving operational efficiency and patient care.
    • Medical Device Connectivity: Monitor the connectivity and performance of WiFi-enabled medical devices, ensuring reliable data collection and transmission for patient monitoring.
  • Educational Institutions
    • Campus Connectivity: Ensure comprehensive WiFi coverage across campus to support e-learning platforms and online resources, enhancing the educational experience.
    • Network Security: Monitor for unauthorized access or network misuse, protecting sensitive information and ensuring compliance with data protection regulations.
  • Hospitality Industry
    • Guest Experience: Use WiFi analytics to offer guests customized services and information, such as event schedules or restaurant promotions, based on their location within the hotel or resort.
    • Operational Efficiency: Analyze guest usage patterns to optimize network performance and support, ensuring guests have a seamless online experience.
  • Smart Cities
    • Public WiFi Management: Monitor and analyze the usage of public WiFi networks to ensure reliable connectivity for citizens and visitors, facilitating access to information and city services.
    • Traffic and Crowd Management: Utilize WiFi analytics for crowd monitoring and management during events, improving safety and the overall experience.
  • Transportation Hubs
    • Passenger Flow Analysis: Monitor WiFi connection data at airports, train stations, or bus terminals to understand passenger flows and optimize operations and staffing.
    • Information and Services: Provide passengers with real-time information on schedules, delays, and services available within the terminal, enhancing the travel experience.

Frequently used Monitoring/Analytics Tools

For WiFi monitoring and analytics, several tools are frequently used by professionals to manage, diagnose, and optimize wireless networks. These tools range from simple utilities for small networks to sophisticated platforms designed for enterprise environments. Here's a list of some of the most commonly used tools:

  • Wireshark
    • Description: An open-source packet analyzer that allows users to see what’s happening on their network at a microscopic level. It's widely used for network troubleshooting, analysis, and protocol development.
    • Use Case: Deep packet inspection to diagnose network problems and ensure secure, efficient data transmission.
  • SolarWinds Network Performance Monitor
    • Description: A comprehensive network performance monitoring tool that can track the health and performance of WiFi networks among other network devices.
    • Use Case: Real-time monitoring and alerts for network performance issues, including wireless network coverage and connectivity problems.
  • PRTG Network Monitor
    • Description: An all-inclusive network monitoring tool that includes WiFi monitoring capabilities, tracking bandwidth, usage, and availability.
    • Use Case: Monitoring WiFi access points and analyzing traffic to ensure optimal performance and quick troubleshooting.
  • NetSpot
    • Description: A WiFi analyzer and survey app for mapping network coverage, visualizing WiFi signal strength, and identifying connectivity issues.
    • Use Case: WiFi planning and deployment, signal strength mapping, and identifying dead zones within a coverage area.
  • AirMagnet WiFi Analyzer
    • Description: A comprehensive tool for WiFi network monitoring and troubleshooting, offering detailed insights into network performance, security, and interference issues.
    • Use Case: Detecting and fixing WiFi connectivity issues, ensuring compliance with security policies, and identifying rogue devices.
  • Ekahau Pro
    • Description: A professional tool for designing, analyzing, optimizing, and troubleshooting WiFi networks, widely used for large and complex environments.
    • Use Case: Comprehensive WiFi site surveys, heatmapping, and network planning to ensure reliable and efficient wireless coverage.
  • Cisco Meraki
    • Description: Offers cloud-managed WiFi solutions with built-in analytics for monitoring network users, devices, and applications in real-time.
    • Use Case: Managing and monitoring WiFi networks remotely, with detailed analytics on user behavior, device performance, and application usage.

An Example of Step by Step Procedure

Let's assume that you have a wireshark log for the following case and think of a step by step analytic process : (This is a use caes example mentioned in previous section and a imaginary situation just to have some big picture about how the analystics goes on).

  • Retail Stores Customer Movement Tracking: Analyze the flow of customers through the store to identify high-traffic areas, optimizing store layout and product placement.
  • Engagement and Loyalty: Offer personalized promotions or information to customers based on their location within the store, enhancing customer engagement and loyalty.

Analyzing WiFi data for customer movement tracking and engagement in a retail store using Wireshark logs involves several steps focused on interpreting signal strength, device connections, and possibly, the use of management frames to understand customer behaviors. While Wireshark itself might not directly capture customer movement without specific network configurations, here's a conceptual approach to how you might analyze relevant data:

Now let's think of how we approach this in step by step.

Step 1: Set Up for Data Capture

  • Ensure that your WiFi infrastructure is configured to log detailed information about device connections and disconnections, signal strength, and access point (AP) interactions. This might involve setting up multiple APs throughout the store to capture data across different zones.

Step 2: Collect Wireshark Logs

  • Capture Wireshark logs during a typical business period or during a specific event/promotion. Focus on capturing management frames, which include device association, reassociation requests, and probe requests/responses that can indicate the presence and movement of WiFi-enabled devices.

Step 3: Filter Captured Data

  • Filter by MAC Addresses: Start by filtering the data for MAC addresses that correspond to customer devices. This can be challenging due to MAC address randomization for privacy, but patterns may still emerge.
  • Probe Requests: Filter for probe requests, which are sent by devices seeking WiFi networks. These can indicate when a device enters or moves within the store.

Step 4: Analyze Signal Strength and AP Connections

  • Signal Strength Analysis: Analyze the signal strength (RSSI) of probe requests and associations to gauge how close devices are to specific APs. This data can help identify high-traffic areas.
  • AP Interaction: Look at which APs devices are connecting to and how often they switch between APs. This can give insights into movement patterns within the store.

Step 5: Time and Duration Analysis

  • Analyze the timestamps of first and last appearances near APs to estimate the duration of visits and identify peak times. Duration near specific APs can indicate interest in particular store areas.

Step 6: Map Data to Store Layout

  • Using signal strength and AP connection data, map device movements to the store layout. This requires knowing the physical location of each AP and interpreting signal strength as an indicator of proximity.

Step 7: Identify Patterns and Insights

  • Look for patterns such as common paths through the store, areas with prolonged dwell times, and times of day with increased activity. These patterns can inform store layout optimizations and targeted engagement strategies.

Step 8: Implement Findings

  • Use insights to adjust store layouts, product placements, and to plan targeted promotions. For example, if certain areas show high traffic but low engagement, consider changing product placements or signage to increase interaction.

Step 9: Personalized Engagement Strategies

  • While Wireshark data alone may not provide enough detail for personalized promotions without integrating with other systems (e.g., WiFi marketing platforms), insights on high traffic and engagement areas can guide where to place QR codes or NFC tags for promotions.

Step 10: Continuous Improvement

  • Regularly analyze Wireshark logs to monitor changes in customer behavior, effectiveness of layout adjustments, and engagement strategies. Use this data for ongoing optimization.
